| Control Mode |
Side-touch mode |
| Chipset |
AD7003D4 |
| Wireless Version |
V5.4 |
| Audio Codec |
SBC / AAC |
| Protocol Support |
A2DP/AVRCP/HFP/HSP |
| Antenna |
Ceramic |
| RF Frequency |
2.402GHz-2.480GHz |
| Power Class |
Class2 |
| RF Receive Sensitivity |
-86dBm |
| Effective Wireless Range |
10米 |
| Power amplifier type |
Built-in chip |
| S/N |
≥90dB |
| Driver |
Full-range speaker |
| frequency response |
20Hz～20KHz |
| Driver Sensitivity |
114±3dB（at 1kHz/1mW,With IEC-711 Coupler） |
| Driver Power |
Rated 8mW |
| MIC |
MEMS, 2718, -42dB±2dB |
| ANC |
No |
| ENC |
Single Mi ENC |
| Earbuds Battery |
Coin cell batteries：3.6V/35mAh |
| Rated input for Earbuds |
5V/30mA |
| Charging time for Earbuds |
1.5h |
| Music time |
Approximately 4.5 hours (80% volume), 19.5 hours with the charging case |
| Talk time |
Approx. 3.5 hours (80% volume) |
| Standby time for Earbuds |
The earbuds are about 70 hours, and the charging case is about 300 hours in standby |
| Case Battery |
Lithium polymer batteries：3.7V/400mAh |
| Rated input for Case |
5V/300mA |
| Charging time for Case |
About 2 hours |
| Times of Case charging Earbuds |
About 4.4 times |
| Storage temperature and humidity |
In a dry and ventilated room, the product should avoid contact with corrosive substances and keep away from fire and heat sources. The product is charged 1 time every 3 months during storage. Temperature: -10~45°C, Humidity: less than 70% |
| Working temperature and humidity |
Temperature: 0~45°C, Humidity: less than 70% |
| Static current for Earbuds |
≤10uA |
| working current for Case |
≤150mA |
| Static current for Case |
≤20uA |
| Storage mode power consumption |
≤20uA |
| Product weight |
41g (earphone approx. 9g, compartment approx. 32g) |
